Automatic Screw Oil Press Machine Introduction

Automatic screw oil press machine is a compound machine which can squeeze and filter oil at the same time. It is with a simple structure, convenient operation, beautiful appearance. Except for feeding materials, the integrated screw oil press can control temperature and vacuum filter automatically. It can squeeze many oil crops including peanuts, soybeans, tea seeds and cottonseeds etc.

Automatic Screw Oil Press Application

Integrated screw oil press is one of the advanced oil presses, it can be widely used for squeezing sesame, rapeseed, peanut kernel, cottonseed, soybean, olive, tea seed and corn germ etc.

Integrated Screw Oil Press Features

1. High oil yield: this automatic screw oil press adopts directional compression, multistage propulsion, and once-squeezing, the oil yield can increase 10% ¡ª30%.
2. Large production quantity: the working efficiency can be improved more than 30% by strengthening the feed system and increasing the propulsion speed.
3. Automatic control: this oil press can control the squeezing temperature automatically; built-in vacuum shunt can make the efficient separation of oil and residue.
4. Safe and convenient: simple structure covering small space; adopt totally enclosed protection to ensure safe and convenient operation.
5. Reliable and durable: adopt quality steel and fatigue-resisting castings to ensure reliable performance, which can realize long time and continuous running; the surface of automatic screw oil press adopts electrostatic spraying, which can resist over-high temperature, clean and delicate.

Integrated Screw Oil Press Benefits

¡ôPure oil: vacuum filtering device of the automatic screw oil press can ensure the pure oil conforming to the health and quarantine standard.
¡ôSaving of labor: this oil press can save 60% labor with the same output, one or two people can produce oil by using the oil press.
¡ôEnergy conservation: automatic screw oil press can decrease 40% power with the same output.
¡ôWide usage: the popular automatic screw oil press machine can press multiple oil crops, high oil yield and large capacity.
¡ôNo temperature limit: this machine is equipped with a temperature control system, the crude oil temperature can be adjusted naturally to achieve quick pure filtration. So it won’t be limited by the seasons or climate.

Integrated Screw Oil Press Working Principle

When the oil press runs, the processed oil materials enter into the squeezing chamber through the hopper. The screw rotor propels the oil materials inward and squeezes them. The oil materials in the squeezing chamber are motorial. In the high-pressure chamber, there is great friction resistance between oil materials and squeezing the spiral or squeezing chamber, thus the micro materials can create friction. On the other hand, the squeezing screw diameter is gradually thickening and the screw pitch is gradually decreasing, so when the squeezing screw rotates, the screw threads can propel the oil materials forward or outward. The heat generated by friction can improve the yield of the oil press, and let the oil flows from the gaps.

Automatic Oil Press Machine Technical Data
